TENMAT FF109 CE Marked Vent Duct Fire Sleeves provide 30 minutes, 1 hour, 2 hour and in certain applications up to 4 hours Fire Resistance to rectangular PVC vent duct penetrations, and are suitable for all common sizes of vent duct. The Fire Sleeves have been fire tested to EN 1366-3:2009 & BS 476. The European Technical Approval (ETA-12/0332) and EC Certificate 2812-CPR-0341 enables the range to be CE Marked and used throughout the EU.
The compressible 25-30mm thick material offers excellent fire performance combined with accommodation for deflection. The Sleeves do not require any additional metal sleeving and are held in place by the plasterboard/batt only. The unique intumescent material is vacuum formed to a shaper which ensures controlled sealing of the duct. In addition, the material swells externally to provider a fire and smoke seal around the sleeve.
TENMAT FF109 CE Marked Vent Duct Fire Sleeves provide 30 minutes, 1 hour, 2 hour and in certain applications up to 4 hours Fire Resistance to rectangular PVC vent duct penetrations, and are suitable for all common sizes of vent duct.
The compressible 25-30mm thick material offers excellent fire performance combined with accommodation for deflection. The Sleeves do not require any additional metal sleeving and are held in place by the plasterboard/batt only. The unique intumescent material is vacuum formed to a shaper which ensures controlled sealing of the duct. In addition, the material swells externally to provider a fire and smoke seal around the sleeve.
Vent Duct Fire Sleeve – Additional Info
- Up to 120 minutes Fire Rated
- CE Marked
- Can be retrofitted
- No metal sleeving required
- Assessed for installation in walls and floors
- Can accommodate deflection
Fire Testing Approvals
The Fire Sleeves have been full scale fire tested to EN 1366-3:2009 & BS 476. The EN fire testing included all ducts tested with Uncapped/Uncapped (U/U) duct end configuration as required for ventilation ducts. The European Technical Approval (ETA-12/0332) and EC Certificate 2812-CPR-0341 enables the range to be CE Marked and used through the EU.
The product is available to suit 110×54, 204×60, 220×90, 234×29, 308×29, 100, 125 and 150mm ventilation ducts and can be used on multiple, side by side rectangular duct penetration including in solid walls and plasterboard partitions.
See downloadable data sheet for more info on product dimensions and availability
Fire Testing Approvals
CE Approved / European Technical Approval ETA-12/0332 Updated 11.02.20
Certificate of Constancy of Performance – 2812-CPR-0341 Updated 11.02.20
Declaration of Performance – Document No. QA027 Updated 11.02.20
CE Approved / European Technical Approval ETA-12/0332
Certificate of Constancy of Performance – 1224-CPR-0341
Declaration of Performance – Document No. QA027
